BDH Compact Automatic Powder Packing Machine

Characteristic Description

The BDH-YD-320 is a compact, high-speed automatic vertical form fill and seal machine tailored for small pouch packaging, such as stick packs, mini sachets, and small pillow bags. It excels in packaging small-volume products, integrating measuring, filling, bag forming, sealing, and counting into a fully automated process. With a maximum speed of 90 packets per minute and a space-saving design (950mm650mm1750mm), it is perfect for small and medium-sized enterprises (SMEs) and workshops with limited space. The machine adapts to a wide range of materials, including powders, granules, candies, and condiments, and supports almost all film types, offering exceptional versatility.

Market Research

Industry Demand for Compact Equipment

SMEs and small workshops face constraints such as limited floor space and budget, creating a demand for compact, cost-effective packaging equipment that doesn’t compromise on speed or quality. The rise of niche markets and personalized products also requires machines that can handle frequent product switches and small-batch production efficiently. Traditional large-scale equipment is often too bulky and expensive for these users, leaving a gap for compact, high-speed models like the BDH-YD-320.

Product Competitive Edge

The BDH-YD-320 addresses this gap with its compact footprint and 90 packets per minute speed—faster than many similarly sized competitors. Its PLC servo system ensures precision, while the touchscreen interface simplifies operation and product switches. The machine also offers a range of optional functions, making it adaptable to diverse needs without the high cost of fully customized large equipment. For SMEs, it provides a cost-effective way to upgrade from manual to automatic packaging, improving efficiency and product quality.

Key Features

Ultra-High Speed: Reaches up to 90 packets per minute, outperforming most compact vertical packaging machines in its class.

Compact Design: Measures 950mm650mm1750mm, saving floor space and fitting into small workshops or production lines.

Intelligent Operation: PLC servo system enhances precision, touchscreen stores product settings, and fault display aids quick troubleshooting.

Multi-Material Adaptability: Handles powders (e.g., milk, coffee), granules (e.g., nuts, rice), candies, condiments, and more, compatible with almost all films.

Safety & Durability: Meets enterprise safety standards, with a one-button emergency stop and silent horizontal motor for long-term reliable use.

This model is widely used in packaging coffee powder, milk powder, ketchup, Salad, Condiments, Candy, Biscuit, Nuts and seeds, it adapts to almost any film type.

Max Speed:85 BPM
Max Bag Size:150 mm W x 190 mm L
Min Bag Size:50 mm W x 40 mm L

· Safety protection meets enterprise safety standards.

· Smart temperature control ensures neat sealing.

· PLC servo system enhances precision and intelligence.

· Auto-completes measuring, filling, bagging, and counting.

· Touchscreen stores settings for quick product changes.

· Fault display aids prompt troubleshooting.

· Produces pillow or perforated bags as needed.

· Single-belt film transport: fast, stable, low wear.

Optional

· Continuous package or multi package with short package cut-off function;

· Hook hole drilling function (round holes and various irregular holes can be drilled);

· Supporting discharge conveyor;

· Various automatic or semi-automatic metering and conveying mechanisms;

· Inflation and exhaust function;

· Compressed air system and nitrogen generator;

Food Industries

· Baked Goods (Biscuits & Cakes)

· Cannabis

· Coffee

· Condiment (ketchup/Mustard Sauce/Jam/mayonnaise/tahini/butter/soy sauce)

· Confectionery (candy/chocolate)

· Dairy Products（Cheese/milk powder）

· Frozen Food (Prawn/Shrimp/Fish/Scallops/Chiken/Peas/Corn/Dumpling/Burger/samosas）

· Fruit & Vegetable（Fresh fruit/Dried Fruit/Peas）

· Food Grains & pulses (Rice/Whole Wheat/rolled oats/millet/corn kernels/legumes/noodles)

· Kimchi & Pickles

· Meat & Poultry (Chicken/pork/beef/beef jerky)

· Pet Food

· Snacks & Chips (Nuts / seeds）

· Seasonings & Spices (seaoning mix/chilli powder/Galic Powder/curry power/Turmeric Powder/salt/)

· Granule(Rice/peas)

· Liquid & Paste(Beverage /Liquor)

· Powder (Milk/Coffee/Spices/Salt/ajinomoto/)

Performance Meets

Speed & Efficiency: 90 packets per minute maximum speed meets the needs of small-batch and medium-volume production.

Bag Size Versatility: Supports bag lengths from 40mm to 190mm and widths from 50mm to 150mm, ideal for mini sachets and stick packs.

Sealing Quality: Smart temperature control ensures neat, leak-proof seals, maintaining product freshness and shelf life.

Energy & Air Efficiency: Operates at 2.3KW power with 6-8 Kgf/cm² compressed air consumption, reducing energy costs for SMEs.

Customized Service

Optional Functions: Offers continuous packaging, multi-package cut-off, hook hole drilling (round/irregular), inflation/exhaust, and more.

Metering Customization: Provides tailored metering and conveying mechanisms for specific materials (e.g., fine powders, sticky pastes).

Auxiliary Equipment: Can be equipped with a discharge conveyor, nitrogen generator, or compressed air system for extended use.

Bag Type Adjustment: Supports pillow bags, perforated bags, or custom bag shapes to match product branding and packaging needs.
